钻机移运技术可以满足在钻机的各主要分系统不进行较大拆卸的情况下，将钻机的各主要分系统整体移运，使现场搬迁安装快捷方便，减少运输车辆。它具有稳定性高，安全系数大，缩短钻井周期，减少工人的劳动强度等优点。

The drilling transfer technology can satisfy to transfer the main subsystems of the driilling rig as a whole without any large disassembly of the main parts of the drilling which makes site relocation and installation fast and convenient, as well as reduces transport vehicles.The utility model has the advantages of high stability, high safety factor, shortening drilling period,and reducing labor intensity of workers, etc

技术参数

TECHNICAL PARAMETERS

◆液压系统额定工作压力：25M PA

◆钻机用液压缸：YG280/150-580

◆单缸额定最大牵引拉力：1100KN

◆单缸额定最大后移推力：1570KN

◆钻机移动步距：580MM

◆设备的移动速度为：200-600MM/MlN

◆泥浆泵用液压缸：YG160/80-500

◆单缸额定最大牵引拉力：380KN

◆单缸额定最大后移推力：500KN

◆泥浆泵移动步距：500MM

◆设备的移动速度为：200-500MM/MIN具有稳定性高，安全系数大，缩短钻井周期，减少工人的劳动强度等优点。

. Rated operating pressure of hydraulic system: 25M pa

. Hydraulic cylinder for drilling rig: YG280/150-580

. Maximum traction force of single cylinder: 1 100KN

. Rated maximum thrust of single cylinder: 1570KN

. Moving distance of drilling rig: 580mm

. Moving speed of equipment: 200-600mm/min

. Hydraulic cylinder for mud pump: YG160/80-500

. Maximum traction force of single cylinder: 380KN

. Rated maximum thrust of single cylinder : 500KN

. Mud pump moving distance: 500mm

. The moving speed of equipment is 200-500mm/min It has the advantages of high stability, high safety factor, shortening drilling period,reducing labor intensity of workers,etc.
